High-rise & Skyscraper Steel Structure
The highest tower in the world
Building height: 1,007m
Comply with AISC, ASTM, AWS
Max. plate thickness: 180mm
Full penetration weld of 180mm thickness
Shop drawing, fabrication and erection
Headquarter for Philippines No. 1 Bank
Building height: 272m & 220m, the tallest steel skyscraper in Philippines
Total steel weight: 32,500t
Building area: 164,400m2
Comply with AISC
Shop drawing, fabrication and erection of steel structure, BRB and Mesh system
Building height: 194.5m
Total steel weight: 1,600t
Triaxial grid system
Comply with AISC
Shop drawing, fabrication and erection
Total steel weight: 10,800t
Comply with AS/NZS, AESS
200m height braced steel frame structure
Full bolt connection at intense seismic area
Pre-camber, on-site survey and compensation technique
The atmospheric corrosion environment reaches the highest C5M level
Shop drawing, fabrication and erection
Total steel weight: 15,000t
High strength thick plate with full penetration butt weld under hot and humid environment
Comply with BS EN
Shop drawing, fabrication and erection
Building height: 155m
Comply with AWS
Hollow and twisting section
3.8m high oversized for inland transportation
Total steel weight: 1,272t
Comply with AS/NZS, AESS
Building height: 145m
End plate bolt connection
Complex sliding joint
6 Star - "Green star" Building
Connection design, shop drawing and fabrication
Total steel weight: 8,700t
Comply with AS/NZS, AESS
Shop drawing, material purchase, fabrication and CIF to Sydney
One of the top 10 architectural awarded buildings in 2008
Total steel weight: 3,500t
Comply with JIS
Building height: 204m
Shop drawing and fabrication
Total steel weight: 9,800t
Comply with BS EN
The main structures are box beam and H-shaped steel column.
Shop drawing and fabrication
Total steel weight: 9,306t
Shop drawing, fabrication and erection
Total steel weight: 40,000t
Building height: 610m
Maximum CHS is 1850mm×60mm
Monthly supply of steel volume: 3,050t
Gold Award of China’s Construction Engineering Steel Structure
Shop drawing, fabrication and erection
Total steel weight: 65,000t
Building height: 492m
Maximum thickness of the steel plate: 100mm
Monthly supply of steel volume: 4,000t
Shop drawing, fabrication and erection
Total steel weight: 50,000t
Building height: 330m
Building area: 300,000m2
Shop drawing and fabrication
Total steel weight: 96,000t
Building height: 530m
Maximum box section: 3.5m×5.6m
Steel frame-core wall system
Shop drawing and fabrication
Total steel weight: 43,000t
Building height: 432m
Maximum cross-section of the round pipe: D1800×55mm
Maximum thickness of the steel plate: 100mm
Monthly supply of steel volume: 2,500t
Gold Award of China’s Construction Engineering Steel Structure
China Construction Engineering Luban Prize
Shop drawing and fabrication
Total steel weight: 50,000t
Building height: 336.9m
Gold Award of China’s Construction Engineering Steel Structure
Shop drawing and fabrication
Total steel weight: 15,000t
Building height: 260m & 250m
Maximum thickness of the steel plate: 60mm
Shop drawing and fabrication
Total steel weight: 9,900t
Building area: 108,000m2
Building height: 105m
Maximum thickness of the steel plate: 140mm
Gold Award of China’s Construction Engineering Steel Structure
Shop drawing, fabrication and erection
Total steel weight: 15,000t
Building area: 178,000m2
Building height: 290m
Designed by the famous American GP company
Building area: 65,000m2
Building height: 100m
Building width: 116m
Gold Award of China’s Construction Engineering Steel Structure
Shop drawing, fabrication and erection
Total steel weight: 13,000t
Building area: 130,000m2
Building height: 85m
Gold Award of China’s Construction Engineering Steel Structure
Shop drawing, fabrication and erection
Total steel weight: 10,000t
Building area: 106,000m2
Building height: 138m
Building outer diameter: 146.6m
Inner diameter: 47 meters
Shop drawing, fabrication and erection
Total steel weight: 22,000t
Building height: 260m
Thousand tones truss between the two buildings erected by hydraulic lifting technique, then lifted into the place by hydraulic jack one-time.
Shop drawing, fabrication and erection
Building height: 250m
Building area: 400,000m2
Shop drawing, fabrication and erection
Total steel weight: 10,000t
Building height: 212m & 198m
Shop drawing, fabrication and erection
Building area: 37,000m2
Sightseeing tower area: 5,100m2
Gold Award of China’s Construction Engineering Steel Structure
Shop drawing, fabrication and erection
Building area: 90,000m2
Building height: 74m、62.3m & 23.3m
External steel frame is looks like “honeycomb”
Shop drawing, fabrication and erection
Total steel weight: 20,000t
Building area: 150,000m2
Building height: 220m
China Construction Engineering Luban Prize
Total steel weight: 44,000t
Building height: 245m
Gold Award of China’s Construction Engineering Steel Structure
Shop drawing, fabrication and erection
Building area: 79,000m2
The main steel structure consists of steel frame core tube structure, frame steel structure and tower crown.
